Local Shop Ecommerce Application - Technical Report

Account Usernames and Passwords

Email Address	Password	First Name	Last Name
admin@email.com	account	Admin	Account
user@email.com	account	User	Account

Features Implemented

Feature	Implemented (Partial / Full)	Comments
Users
Register a new account	Full
Login to the application	Full
Logout of the application	Full
View all categories	Full
Add a product to their basket	Full
Create an order	Full
View all previous orders	Full
Admins
Create a new product/category	Partial	New items created by admin will not be added to database because the item id is not unique
Products
Are assigned to categories	Full
Have a name	Full
Have an image	Full
Have a description	Full
Have a price	Full
Have multiple versions	Full
Can be shown as in stock	Full
Can be shown as out of stock	Full
Additional Features
Admin can view all orders	Full

Design Implementation

Creating Login Functionality

Initially, I created a public method inside of the ‘MainActivity’ class that sets the value of the boolean variable ‘loggedIn’. Then I would call that method from the ‘LoginActivity; class to change the value of ‘loggedIn’. However, this did not function as I had expected. The ‘LoginActivity’ would refresh when the ‘login’ button was pressed despite a correct email and password being entered.

MainActivity:

LoginActivity:

Recognising the fundamental flaws of my original plan to track if a user is logged in, I decided to change tactics and use a shared preference instead. I created a new class called ‘LoginUtils’; this class contains the setter and getter for the login status. I added the necessary lines of code in the ‘MainActivity’ class and ‘LoginActivity’ class for this to function correctly.

A benefit of using shared preferences is that even after closing the application the user will still be registered as logged in.

LoginUtils:

MainActivity:

LoginActivity:

Class Diagram

Screenshots of System showing Key Features

Testing

Description	Expected Outcome	Actual Outcome	Result
Login Activity
User presses ‘login’ button with a correct email and password Note: Empty email address and password is considered a correct email and password for this test	User will be taken to the home page	Login page refreshes	FAIL
User presses ‘login’ button with a correct email and password Note: Empty email address and password is considered a correct email and password for this test	User will be taken to the home page	User was taken to the home page	PASS
User presses ‘login’ button with email and password exists in the database	Database will check if a user with that email exists in the database and return true. Database will check if that email has a password that matches the entered password and return true. User will be taken to the home page	Database checks if a user with that email exists in the database returning true. Database checks if that email has a password that matches the entered password returning true. User is taken to the home page	PASS
User presses ‘login’ button with email that exists in the database and a password that doesn’t match	Database will check if a user with that email exists in the database and return true. Database will check if that email has a password that matches the entered password and return false. A text view will display ‘incorrect credentials. User will stay on the login page	Database checks if a user with that email exists in the database returning true. Database checks if that email has a password that matches the entered password returning false. A text view displays ‘incorrect credentials. User stays on the login page	PASS
User presses ‘login’ button with email that doesn’t exist in the database	Database will check if a user with that email exists in the database and return false. A text view will display ‘account doesn’t exist’. User will stay on the login page	Database checks if a user with that email exists in the database returning false. A text view displays ‘account doesn’t exist’. User stays on the login page	PASS
User presses the ‘click here to register’ button	User will be taken to the register page	Nothing happens. User stays on the login page	FAIL
User presses the ‘click here to register’ button	User will be taken to the register page	User is taken to the register page	PASS
Register Activity
User presses the ‘register’ button where none of the data is filled	A text view will display ‘all fields are required’. User will stay on the register page	A text view doesn’t display ‘all fields required’. User stays on the register page	FAIL
User presses the ‘register’ button where none of the data is filled	A text view will display ‘all fields are required’. User will stay on the register page	A text view displays ‘all fields required’. User stays on the register page	PASS
User presses the ‘register’ button where the email entered already exists in the database and the other data is filled	A text view will display ‘account already exists’. User will stay on the register page	A text view displays ‘account already exists’. User stays on the register page	PASS
User presses the ‘register’ button where the email entered is not in the database and the other data is filled	User will successfully register - the user data will be added to the database. User will be taken to the home page	User successfully registered – the data is added to the database. User is taken to the home page	PASS
Main Activity
User presses ‘shop’ navigation button	User will be taken to the categories page	User is taken to the categories page	PASS
User presses ‘basket’ navigation button	User will be taken to the basket page	User is taken to the basket page	PASS
User presses ‘account’ navigation button	User will be taken to the account page	User is taken to the account page
User presses ‘home’ navigation button	User will be taken to the home page	User is taken to the home page	PASS
Categories Fragment
User presses ‘singles’ category button	User will be taken to shop fragment that shows all the items that are in the singles category	User is taken to shop fragment that shows all the items that are in the singles category	PASS
User presses ‘booster boxes’ category button	User will be taken to shop fragment that shows all the items that are in the booster boxes category	User is taken to shop fragment that shows all the items that are in the booster boxes category	PASS
User presses the ‘boosters’ category button	User will be taken to shop fragment that shows all the items that are in the boosters category	User is taken to shop fragment that shows all the items that are in the boosters- category	PASS
Shop Fragement
User presses an item card	User will be taken to the item page fragment displaying the data of the item card the user pressed	User is taken to the item page fragment displaying the data of the item card the user pressed	PASS
Item Page Fragment
User presses ‘add to basket’ button	The item shown on the item page will be added to the user’s basket	The item shown on the item page is added to the user’s basket	PASS
Basket Fragment
User presses ‘checkout’ button with an empty/less than 10 characters in the address field	A toast will display ‘address has to be more than 10 characters’	A toast will display ‘address has to be more than 10 characters’	PASS
User presses ‘checkout’ button with the address field filled with 10 or more characters	The item(s) in the basket will be added to the database and the order will be viewable on the account page	The item(s) in the basket are added to the database and the order is viewable on the account page	PASS
Account Fragment
User presses ‘account’ navigation button	User will be taken to the account page where they can view all their orders	User is taken to the account page and can view all their orders	PASS

Bug List

• I do not consider the following a true error as the code works as expected and does not error when run: cursor.getColumnIndex() has a red line under it:Example: DatabaseConnect in function passwordCheck()

• New items created by admin will not be added to database because the item id is not unique

• Cannot add new item from the floating button on the categories fragment

• Changing the spinner on an item does not update the price or image of the item

---

Attributions

• Cart Remove: https://pictogrammers.com/contributor/Simran-B/

• Cart Plus, Cart outline, store outline, plus, and home outline: https://pictogrammers.com/contributor/google/

• Account cog outline: https://pictogrammers.com/contributor/mririgoyen/

• Magic the Gathering merchandising images: Owned by Wizards of the Coast / Hasbro
